iTC-1 / Programmable wall control for OEMs
A 3.5" capacitive touch panel with a fully programmable GUI. Multi-page custom interfaces on one wall panel. Fits a standard 2-gang box. Power and RS232/RS485 control over a single CAT5 run up to 1,000 ft.
Explore the iTC-1 Talk to engineering
Core capabilities
Full GUI design software is included. Multi-page custom interfaces on one wall panel. Colors, graphics, and plate finish follow the brand.
Installs in a 2-gang or re-work box. 4.5 × 4.5 × 1.25 in, 6.6 oz.
24 VDC power plus RS232 or RS485 control over CAT5/CAT5e, up to 1,000 ft.
Programmable security lockout, light-based auto-dimming, and tactile audio feedback.
Heritage
Ivie Technologies has designed and built professional audio measurement and control equipment in Utah for decades. System designers know the company from the IE-series analyzers, iFlex digital mixers, and related tools used in installed sound, cinema, and live production.
The current product is the iTC-1 — a programmable wall controller for OEM equipment and installed AV. Documentation and software for discontinued products remain available for download. The factory does not take support inquiries for those products.
Applications
The 3.5" panel is 320×240 with 24-bit color. Photographs, branded art, floor plans, and giant volunteer buttons all fit — and those examples are home pages, not the whole layout. Same hardware, different GUI, different job.
A source page with photo tiles and volume. The camera tile can open a PTZ page without leaving the wall.
Scene presets on a photo wallpaper. Event can jump to a private-dining page for music and lighting.
Operator presets on the home page; a hidden hotspot can open a technician page.
